Payment Terms
|
T/T
|
EXW
|
30% in advance for deposit payment, the balance payments will be paid before shipment.
|
|
|
FOB
|
||||
|
CFR/C&F
|
30% in advance for deposit payment, the balance will be paid against copy of B/L
|
|||
|
CIF
|
||||
|
L/C
|
Optional for the amount of above 50,000 usd, L/C at sight is acceptable.
|
|||
|
West Union
|
Optional for amount of order less than 5000 usd
|
|||
|
Paypal
|
||||
|
Delivery Time
|
7~30 days after receiving the payment or the deposit payment
|
|||
|
Model
|
KY-EST30KH
|
KY-EST40KH
|
KY-EST50KH
|
KY-EST60KH
|
|
|
Efficiency
|
Max.Efficiency
|
>98.2%
|
>98.2%
|
>98.2%
|
>98.2%
|
|
PV Input parameters |
Max. PV input power(W)
|
36000
|
48000
|
60000
|
72000
|
|
Max. PV input voltage(d.cV)
|
1000
|
1000
|
1000
|
1000
|
|
|
MPPT Operation Voltage Range(V)
|
300-900
|
400-900
|
400-900
|
450-900
|
|
|
Number of MPPT channels and Strings
|
2/2/2
|
2/2/2
|
2/2/2/2
|
2/2/2/2
|
|
|
Max. PV input current(A)
|
36/36/36
|
36/36/36
|
36/36/36/36
|
36/36/36/36
|
|
|
Max Short-circuit current of PV input(A)
|
42/42/42
|
42/42/42
|
42/42/42/42
|
42/42/42/42
|
|
|
Starting voltage
|
180
|
180
|
180
|
180
|
|
|
Battery
|
Max Input/Output Voltage(V)
|
800
|
800
|
800
|
800
|
|
Operating Voltage Range(V)
|
220-800
|
220-800
|
220-800
|
220-800
|
|
|
Max Charge/Discharge Current(A)
|
100/100
|
100/100
|
100/100
|
100/100
|
|
|
Max Input/Output Power(W)
|
30000
|
40000
|
50000
|
60000
|
|
|
Battery Type
|
Li-ion/Lead-acid
|
Li-ion/Lead-acid
|
Li-ion/Lead-acid
|
Li-ion/Lead-acid
|
|
|
AC Input and Output |
Rated Power(W)
|
30000
|
40000
|
50000
|
60000
|
|
Max. Apparent AC Power(VA)
|
3000
|
40000
|
50000
|
60000
|
|
|
Nominal AC Voltage(Vac)
|
400, 3L/N/PE
|
400, 3L/N/PE
|
400, 3L/N/PE
|
400, 3L/N/PE
|
|
|
AC Power Frequency(Hz)
|
50/60
|
50/60
|
50/60
|
50/60
|
|
|
Max. AC Output Current(A)
|
45
|
60
|
75
|
87
|
|
|
Power Factor Range
|
0.8 ind…0.8 cap
|
||||
|
OutputTHDi(@Nominal Output)
|
<3%
|
<3%
|
<3%
|
<3%
|
|
|
Off-Grid AC Output (Back-up AC Output) |
Rated Output Power(W)
|
30000
|
40000
|
50000
|
60000
|
|
Max. Apparent AC Output Power(VA)
|
30000
|
40000
|
50000
|
60000
|
|
|
Nominal AC Output Voltage(Vac)
|
400,3L/N/PE
|
400,3L/N/PE
|
400,3L/N/PE
|
400,3L/N/PE
|
|
|
AC Power Frequency(Hz)
|
50/60
|
50/60
|
50/60
|
50/60
|
|
|
Max. AC Output Current(A)
|
45
|
60
|
75
|
87
|
|
|
Genaral Data
|
Operating Temperature Range
|
-25°C …+60°C(>45°C derating)
|
|||
|
Operating Altitude(m)
|
<=4000m(>=2000m derating)
|
||||
|
Noise(dB)
|
<40
|
||||
|
Topology
|
Transformerless
|
||||
|
Cooling Method
|
Intelligent Fan
|
||||
|
Ingress Protection Rating
|
IP54
|
||||
|
Relative Humidity
|
5-90%
|
||||
|
DC interface type
|
Push-in terminal
|
||||
|
AC interface type
|
Terminal block
|
||||
|
Display
|
LCD
|
||||
|
Communication With Portal
|
RS485 (WiFi/GPRS Optinal)
|
||||
|
Communication With BMS
|
CAN
|
||||
|
Communication With Meter
|
RS485(Wifi/GPRS optional)
|
||||
|
Mounting Method
|
Wall-mounted/floor-standing
|
||||
|
Dimensions (W*D*H)(mm)
|
800*600*280
|
||||
|
Weight(Kg)
|
50
|
50
|
50
|
50
|
|
|
Certification
|
Safety
|
IEC62109-1/-2
|
|||
|
EMC
|
EN61000-6-l/-2/-3,IEC61000
|
||||
|
On-Grid standard
|
AS4777.2,NRS097-2-l:2017
|
||||
| OUTPUT POWER | 30kw, 40kw, 50kw |
|---|---|
| GIFT OPTION | NO, YES |
